YMIN (Power)

YMIN, established in 2001, is a top leading manufacturer of high quality capacitors. Products includes Aluminum Electrolytic Capacitor (Radial Leaded Type, SMD Type, Snap-In Type, and Screw Terminal Type), Conductive Polymer Aluminum Solid Electrolytic Capacitor, Conductive Polymer Hybrid Aluminum Solid Electrolytic Capacitor, MLPC, MLCC and EDLC.

With over 20 years of expertise in manufacturing, YMIN is able to ensure quality and timely delivery. Based on the close technical cooperation with counterparts in Japan and South Korea, YMIN products’ performance are superior especially on enduring high temperature, high voltage, high ripple current and high frequency.

YMIN products are ROHS \ REACH certified.  YMIN are certified with ISO9001 \ ISO14001 \ OHSAS18001 \ IATF16949: 2016.

YIM also qualified by NGMC and The Fifth Institute of Electronics. In 2019 YMIN were approved by AEC-Q200 protocols obtained ISO/TS16949 of automotive industry standard.

General Application:
USB Quick Chargers, LED Lighting Devices, EV Electronics, Smart Power Meters, Frequency Converters, UPS Power Supply, EV Car Charging Pile, Electric Welding Machine, Hand-held Electric Tools, Motor Controls, 5G, IoT technology etc.

TYPE SERIES Life (Hours) FEATURES VOLTAGE(V.DC) CAPACITANCE (uF) TEMP (°C)
SNAP IN TYPE CN3 3000 Utral-Low Temperature, High Stability, Low LC,AEC-Q200 350-500 47-1000 -40 - +85
CN6 6000 Utral-Low Temperature, High Stability, Low LC, AEC-Q200 350-500 68-1000 -40 〜+85
CW3 3000 Utral-Low Temperature, High Stability, Low LC, AEC-Q200 350-500 47-1000 - 40 〜+105
CW3S 3000 Small Size, Utral-Low Temperature, High Stability, Low LC, AEC-Q200 350-500 47-1000 - 40 ~+105
CW6 6000 Utral-Low Temperature, High Stability, Low LC, AEC-Q200 350-500 82-1000 -40 ~+105
SN3 3000 Standard, High Ripple Current 16-500 100-56000 -40 (25) ~ +85
SN6 6000 Long Life, High Ripple Current 16-500 82-2200 -40 (25) ~ +85
SW3 3000 Standard, High Ripple Current 16-500 68-47000 -40 (25) -+105
SW6 3000 Life Life, High Ripple Current 400-450 47-56000 -40 (25) -+105
SH15 3000 15mm Height, High Ripple Current 160-400 39-390  -25 - +105
CKD Customer-made
SCREW TERMINAL TYPE ES3 3000 Standard, High Riple Current 200-500 1000-47000 -40 ( 25) ~ +85
ES3M 3000 Small Size, High Ripple Current 200-500 1000-47000 -40 ( 25) ~ +85
ES6 6000 Long Life, High Ripple Current 200-500 1000-47000 -40 (25) ~ +85
EW3 3000 Standard, Wide Temperature Range 200-500 1000-47000 -40 (25) -+105
EW6 6000 Long Life,Wide Temperature Range, High Ripple Current 350-500 1000-22000 -40 (25) -+105
EH3 3000 Ultra-High Voltage 550 〜630 1000-10000 -25 - +85
EH6 6000 High Voltage, Long Life 550 〜630 1000-10000 -25 - +85
EKD Customer-made
